Mainly used for measuring the surface gloss of materials in industries such as spraying, plastic, printing, l, ceramics, building materials, leather, paint, etc.
Standard:DIN 67530、ISO 2813,ASTM D 523,JIS Z8741、BS 3900 Part D5、JJG696
Technical Parameter
Measuring angles
60 °
Measurement spot (mm)
60 °: 9 * 15
Measurement range
60 °: 0-1000GU
Resolving power
0.1GU
Measurement mode
Simple mode, standard and sample measurement mode
Measurement repeatability accuracy
0-100GU: 0.2GU 100-1000GU: 0.2% GU
Measurement accuracy
Meet the requirements of JJG 696 Level 1 working glossmeter
Measurement time
0.5s
Data storage
Can store 100 standard samples and 10000 samples
Size (mm)
165 * 51 * 77 (length * width * height)
Weight
Approximately 400g
Language
Simplified Chinese, English
Battery level
3000mAh lithium battery
Interface
USB, Bluetooth (optional)
Upper computer software
include
Working temperature
0-40 ℃
Humidity
Less than 85%, no condensation
Parts
5V/2A charger, USB data cable, manual, CD, calibration standard board
